Productnummer: 3484694
DIGITUS - solar cable extension - MC4 to MC4 - 3 m
Solar cable extension, MC4 (P) naar MC4 (R), IP65/IP68/IP67, 1500 V, 30 A, 3 m, halogeenvrij, binnen/buiten, zwart, rood (pak van 2)
36,43 €
30,11 € excl. BTW
Goedkoopste privé verzending 6,99 €
Extern magazijn, 4 - 5 werkdagen levertijd
The DIGITUS solar cable extension offers reliable performance with robust features designed for various applications. This cable, compliant with IP65, IP67, and IP68 standards, ensures protection against environmental factors, making it suitable for both indoor and outdoor use. The MC4 connectors provide easy connection and disconnection without the need for tools, enhancing convenience and flexibility in installations. With a cable cross section of 6 mm2, it supports a rated voltage of 1500 V and a rated current of 30 A, accommodating demanding power requirements. Its construction includes flame-retardant and UV-resistant materials, ensuring durability in challenging conditions, while the excellent insulation resistance and minimal contact resistance enhance electrical safety and efficiency.
Producent
Productnummer
3484694
Model
DK-SCEC66-0050
EAN
4016032501817
Naar de website van de producent
Productbeschrijving
DIGITUS - solar cable extension - MC4 naar MC4 - 3 m
Type
Solar cable extension
Aantal in verpakking
2 (weergegeven specificaties zijn voor één artikel)
Functies
Halogeenvrij, binnen/buiten, vlamvertragend, flexibel, weerbestendig, gereedschapsloos type, uv-bestendig, -40°C to 85°C operating temperature, 6 mm² cable cross section, corrosion protection, 0.5 Ohm contact resistance, PPE/PA 66 plug, 4.4 mm insulation diameter, 3 mm conductor diameter, 500 MOhm insulation resistance, 7 kV spark test
Kabellengte
3 m
Connector
MC4 - stekker
Aansluiting (tweede uiteinde)
MC4 - stopcontact
Nominale spanning
1500 V
Nominale stroom
30 A
Conformiteitsnormen
IP65/IP68/IP67
Kleur
Zwart, rood
Algemeen
Aantal in verpakking
2 (weergegeven specificaties zijn voor één artikel)
Type
Solar cable extension
Beschermingsmateriaal
Dwarsgekoppeld polyolefine
Materiaal van omhulsel
Cross-linked polyolefin (XLPO)
Nominale spanning
1500 V
Nominale stroom
30 A
Vlakke aansluiting
Koper
Functies
Halogeenvrij, binnen/buiten, vlamvertragend, flexibel, weerbestendig, gereedschapsloos type, uv-bestendig, -40°C to 85°C operating temperature, 6 mm² cable cross section, corrosion protection, 0.5 Ohm contact resistance, PPE/PA 66 plug, 4.4 mm insulation diameter, 3 mm conductor diameter, 500 MOhm insulation resistance, 7 kV spark test
Kabellengte
3 m
Diameter buitenkant
6.1 mm
Kleur
Zwart, rood
Gewicht
830 g
Connectiviteit
Connector
MC4 - stekker
Aansluiting (tweede uiteinde)
MC4 - stopcontact
Diversen
Conformiteitsnormen
IP65/IP68/IP67, UL 94 V-0, IP67, IP68, IP65, EN 60332-1-2, EN 50618, EN 62852:2015
Afmetingen & gewicht (transport)
Verzendbreedte
19 cm
Verzenddiepte
19 cm
Verzendhoogte
7 cm
Verzendgewicht
890 g
