Productnummer: 3266342

Corsair SF Series SF850 (2024) Voeding - 850 Watt - 92 mm - ATX 3.1 - 80 Plus 80 PLUS Platinum

Voeding ( intern ), SFX standard: ATX12V 3.1, 80 plus Platinum, Cybenetics: Platinum efficiëntie / A- geluidsniveau, 92mm koeling met zero RPM mode technologie en fluid dynamic lager, actieve PFC, kabels: 3 x 8 (6+2) pins voor grafische kaarten / 1 x 12V-2x6 600 Watt pins voor grafische kaarten (PCI Express 5.1 ready) / 8 x 5 pins SATA / 3 x 4 pins Molex / 1 x 24 (20+4) pins ATX / 2 x 4+4 pins CPU, volledig modulair en dun kabels, kleur: zwart, 850 watt

Gratis verzending DPD Pickup (privé)
Extern magazijn, 4 - 5 werkdagen levertijd (verwacht in eigen magazijn 19-8-2026)

The CORSAIR SF Series SF850 power supply is a high-performance and reliable choice for PC enthusiasts and professionals. With an 80 PLUS Platinum certification, it delivers exceptional energy efficiency, reducing operating costs and environmental impact. The SF850 is equipped with a 92 mm cooling fan that features fluid dynamic bearings, ensuring quiet operation and effective cooling, further enhanced by a Zero RPM fan mode for silent performance under low to medium loads. Its fully modular design allows for a clean and organized build, offering flexibility with a variety of cable types and lengths. Safety is paramount, and the SF850 addresses this with multiple protection features, guarding against overheat, overpower, overvoltage, and more. Whether for a gaming setup or a professional workstation, the SF850's compatibility with ATX12V 2.31/ EPS12V 2.92 standards ensures it can power demanding systems.

Voedingskabel (intern)

Producent
Productnummer
3266342
Model
CP-9020256-EU
EAN
0840006663287
Naar de website van de producent
Neem contact op met de fabrikant
Productbeschrijving
CORSAIR SF Series SF850 - voeding - 850 watt
Type apparaat
Voeding - intern
Naleving van specificatie
ATX12V 3.1/ EPS12V
80 PLUS-Certificatie
80 PLUS Platinum
Lokalisatie
Europa
Input Voltage
100-240 Volt wisselstroom V
Output Voltage
+3.3, +5, +12 V
Stroomcapaciteit
850 watt
Stroomafgifte
+3.3V - 20 A
+5V - 20 A
+12V - 70.8 A
+5VSB - 3 A
Uitgangsaansluitingen
1 x voeding 24 pins-ATX met afneembaar 4 pin-deel
2 x voeding 8 pins-EPS12V met afneembaar 4 pins-ATX12V-deel
3 x 8 pins-PCI Express-voeding met afneembaar 2 pins-deel
1 x 12VHPWR
3 x 4-PIN interne voeding
8 x 15 pins Serial ATA-voeding
Modulair kabelbeheer
Ja
Koelingsysteem
92 mm ventilator
Meegeleverde accessoires
Kabelbinders
Afmetingen (BxDxH)
12.5 cm x 10 cm x 6.35 cm

Algemeen

Type apparaat
Voeding - intern
Naleving van specificatie
ATX12V 3.1/ EPS12V
PSU-formaat
SFX
Lokalisatie
Europa

Voeding

Input Voltage
100-240 Volt wisselstroom V
Vereiste frequentie
47 - 63 Hz
Stroomuitgang Connector Details
1 x voeding 24 pins-ATX met afneembaar 4 pin-deel
2 x voeding 8 pins-EPS12V met afneembaar 4 pins-ATX12V-deel
3 x 8 pins-PCI Express-voeding met afneembaar 2 pins-deel
1 x 12VHPWR
3 x 4-PIN interne voeding
8 x 15 pins Serial ATA-voeding
Output Voltage
+3.3, +5, +12 V
Stroomcapaciteit
850 watt
Stroomafgifte
+3.3V - 20 A
+5V - 20 A
+12V - 70.8 A
+5VSB - 3 A
Modulair kabelbeheer
Ja
80 PLUS-Certificatie
80 PLUS Platinum

Diversen

Meegeleverde accessoires
Kabelbinders
Kabels meegeleverd
Netvoedingskabel
ATX-stroomkabel 30 cm
16 pins-12VHPWR voedingskabel 40 cm
2 x voeding 8 pins +12 V met afneembare 4 pins-sectie-modulaire kabel 40 cm
3 x 8 pins PCI Express-voeding met afneembare 2 pins sectie-modulaire kabel 40 cm
2 x stroom 15 pins-SATA-kabel 44.5 cm
4 pins interne stroomkabel 33 cm
MTBF (gemiddelde tijd tussen twee storingen)
100,000 uur
Koelingsysteem
92 mm ventilator
Functies
Vloeistofdynamische lager koelventilator, geheel modulair, Nul RPM ventilatormodus, bescherming tegen te laag voltage, voltagebeschermer, kortsluitingsbeveiliging, bescherming tegen te hoog voltage, bescherming tegen oververhitting

Garantie van de fabrikant

Service & Support
Beperkte garantie - 7 jaar

Omgevingsparameters

Max. gebruikstemperatuur
50 °C

Afmetingen & gewicht

Breedte
12.5 cm
Diepte
10 cm
Hoogte
6.35 cm
