Productnummer: 2823550
Blackmagic UltraStudio 4K Mini
The new UltraStudio 4K Mini model is a portable Thunderbolt 3 capture and playback solution packed with the latest broadcast technology, including 12G‑SDI, HDMI 2.0 and analog connections.
1.129,83 €
933,74 € excl. BTW
Goedkoopste privé verzending 6,99 €
Extern magazijn, 5 - 6 werkdagen levertijd
The new UltraStudio 4K Mini model is a portable Thunderbolt 3 capture and playback solution packed with the latest broadcast technology, including 12G‑SDI, HDMI 2.0 and analog connections. You get broadcast quality 8 and 10‑bit high dynamic range capture in all formats up to 4K DCI at 60p, and 12‑bit high dynamic range capture in all formats up to 4K DCI at 30p. The front panel features push button controls, an LCD for monitoring signal and setup, an XLR microphone input and a ¼" headphone jack. UltraStudio 4K Mini features USB for connecting a keyboard and mouse, plus it will trickle charge your laptop computer when connected to the Thunderbolt 3 port. There’s even a built in SD card reader allowing instant access to your camera media cards!
Producent
Productnummer
2823550
Model
BM-BDLKULSDMINI4K
EAN
9338716006087
Naar de website van de producent
Productbeschrijving
Blackmagic UltraStudio 4K Mini Thunderbolt 3 capture and playback device
Type
Thunderbolt 3 capture and playback device
Ondersteunde videostandaarden
PAL, NTSC
Afmetingen (BxDxH)
21 cm - 17.7 cm - 4.61 cm
Gewicht
1.2 kg
Algemeen
Type
Thunderbolt 3 capture and playback device
Breedte
21 cm
Diepte
17.7 cm
Hoogte
4.61 cm
Gewicht
1.2 kg
Studio- & productieapparatuur
Ondersteunde videostandaarden
PAL, NTSC
Kenmerken
SD-kaartsleuf, 4K60-signaalondersteuning
Voeding
Vereiste netspanning
120/230 V wisselstroom
Energieverbruik
75.3 Watt
Terminals
Terminals
(1) x microfoon - 3-PIN XLR
(1) x hoofdtelefoon - connector stereo 6,3 mm
(1) x 12G-SDI-ingang - BNC - met doorlus
(2) x 12G-SDI-uitgang - BNC
(1) x HDMI-ingang - 19-pens HDMI Type A
(1) x HDMI-uitgang - 19-pens HDMI Type A
(1) x ingang componentvideo / composietvideo - BNC x 3
(1) x REF-ingang - BNC
(1) x serieel - 9-pens D-Sub (DB-9) - RS-422
(1) x Thunderbolt 3 port - USB-C
(1) x USB 3.1 Gen1 - USB-C
(2) x gebalanceerde audio-ingang - connector stereo 6,3 mm
(2) x gebalanceerde geluidsuitgang - connector stereo 6,3 mm
(1) x hoofdtelefoon - connector stereo 6,3 mm
(1) x 12G-SDI-ingang - BNC - met doorlus
(2) x 12G-SDI-uitgang - BNC
(1) x HDMI-ingang - 19-pens HDMI Type A
(1) x HDMI-uitgang - 19-pens HDMI Type A
(1) x ingang componentvideo / composietvideo - BNC x 3
(1) x REF-ingang - BNC
(1) x serieel - 9-pens D-Sub (DB-9) - RS-422
(1) x Thunderbolt 3 port - USB-C
(1) x USB 3.1 Gen1 - USB-C
(2) x gebalanceerde audio-ingang - connector stereo 6,3 mm
(2) x gebalanceerde geluidsuitgang - connector stereo 6,3 mm
Omgevingsparameters
Min. gebruikstemperatuur
0 °C
Max. gebruikstemperatuur
50 °C
Luchtvochtigheidsgraad bij gebruik
0 - 90% (niet condenserend)
Garantie van de fabrikant
Garantie
3 jaar
Bovenstaande specificaties en vermeldingen kunnen zonder voorafgaande kennisgeving door de fabrikant worden gewijzigd. Sommige teksten kunnen automatisch of machinaal zijn gegenereerd en daardoor misleidende teksten opleveren.
