Productnummer: 2908144
Ever DUO 850 AVR USB
UPS, 230 Volt wisselstroom V, 550 watt, 850 VA, 1-fase, 2 x batterij, Loodzuur, 5 Ah, USB, uitgangen: 6
119,08 €
98,41 € excl. BTW
Goedkoopste privé verzending 6,99 €
Bestelproduct, 8 - 9 werkdagen levertijd
DUO AVR USB series UPS units are perfect for protecting home and office equipment. They provide protection against power drops and losses in the grid, consequently increasing the life and reliability of the connected equipment. Their main purpose of the DUO AVR USB series UPS units is to protect computers, telecom equipment (switches, routers), monitors and fiscal devices.This series of UPS units comes with an HID USB communication interface that lets the UPS operate with other devices, without having to install any software. Moreover, thanks to the in-house developed PowerSoft software you can monitor and configure the DUO AVR USB UPS unit. With the free software the user can access information on the UPS unit's operating mode, its load, battery charge level and the duration of autonomous operation. AVR, a built-in system for regulating (increasing and decreasing) the mains voltage adjusts incorrect input voltage to a level that is acceptable to the receivers, without the use of battery power.The UPS features a system that automatically restarts the device if the battery is discharged and once the power is back, and the "cold start" function allows to start the UPS without a connection to the mains.
Producent
Productnummer
2908144
Model
T/DAVRTO-000K85/00
EAN
5907683605131
Productbeschrijving
EVER DUO 850 AVR USB - UPS - 550 watt - 850 VA - Loodzuur - 5 Ah
Type apparaat
UPS - extern
Gewicht
6.9 kg
Bedradingsingang
1-fase
Input Voltage
230 Volt wisselstroom V
Output Voltage
230 Volt wisselstroom V
Stroomcapaciteit
550 watt / 850 VA
Invoerconnectors
1
Uitgangsaansluitingen
6 x voeding IEC 60320 C13 10A
Batterij
Loodzuur - 5 Ah
Aantal batterijen
2
Looptijd (maximaal)
1.5 min. bij volledige belasting
Netwerkgebruik
USB
Afmetingen (BxDxH)
10 cm x 32.5 cm x 18.9 cm
Algemeen
Type apparaat
UPS - extern
Voeding
UPS-technologie
Line interactive
Input Voltage
230 Volt wisselstroom V
Bereik ingangsspanning
162 - 290 V wisselstroom
Frequentie meegeleverd
50/60 Hz
Bedradingsingang
1-fase
Vereiste frequentie
50/60 Hz
Invoerconnectors
1
Stroomuitgang Connector Details
6 x voeding IEC 60320 C13 10A
Output Voltage
230 Volt wisselstroom V 50/60 Hz
Maximum elektrische stroom
10 A
Stroomcapaciteit
550 watt / 850 VA
Uitgangsgolfvorm
Stapsgewijze benadering van een sinusgolf
Stroompiekonderdrukking
Ja
Circuitbeveiliging
Stroomonderbreker
Batterij
Aantal
2
Technologie
Loodzuur
Geleverde netspanning
12 V
Capaciteit
5 Ah
Run time (tot aan)
1.5 min bij volledige belasting
3 min bij 80% belasting
8 min bij halve lading
1 min bij 110% belasting
3 min bij 80% belasting
8 min bij halve lading
1 min bij 110% belasting
Herlaadtijd
8 uur
Overdrachtstijd
6 ms
Functies
Onderhoudsvrij
Netwerkgebruik
Remote Management Interface
USB
Uitbreiding / Aansluiting
Interfaces
1 x beheer (USB) - 4-pins USB type B
Diversen
Kabels meegeleverd
Voedingskabel - geïntegreerd
Functies
Koude start-functie, Automatic Voltage Regulation (AVR), kortsluitingsbeveiliging, overladingsbescherming, ondersteuning voor VRLA-batterij, hoorbaar alarm, zichtbaar alarm
Conformiteitsnormen
EN 62040-1, EN 62040-2
Software / Systeemvereisten
Software meegeleverd
PowerSoft Professional
Garantie van de fabrikant
Service & Support
Beperkte garantie - onderdelen en werkuren - 2 jaar
Beperkte garantie - batterijen - 1 jaar
Beperkte garantie - batterijen - 1 jaar
Omgevingsparameters
Min. gebruikstemperatuur
0 °C
Max. gebruikstemperatuur
40 °C
Afmetingen & gewicht
Breedte
10 cm
Diepte
32.5 cm
Hoogte
18.9 cm
Gewicht
6.9 kg
Afmetingen & gewicht (transport)
Verzendbreedte
14.1 cm
Verzenddiepte
36.2 cm
Verzendhoogte
25.6 cm
Verzendgewicht
7.6 kg
Bovenstaande specificaties en vermeldingen kunnen zonder voorafgaande kennisgeving door de fabrikant worden gewijzigd. Sommige teksten kunnen automatisch of machinaal zijn gegenereerd en daardoor misleidende teksten opleveren.
