Productnummer: 3238103

TRENDnet TPE-3524SF - switch - 52-port web - 52 ports - smart - rack-mountable - TAA Compliant

Switch, 52-port, web, L2+, intelligent, 48 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+, desktop, rack-uitvoering, PoE+ (740 W), TAA Compliant

759,77 € 627,91 € excl. BTW
Goedkoopste privé verzending 6,99 €
Extern magazijn, 4 - 5 werkdagen levertijd

TRENDnet's 52-Port Gigabit Web Smart PoE+ Switch with 10G SFP+ ports, model TPE-3524SF, offers advanced L2+ features with enhanced traffic management controls to meet the evolving demands of SMB networks. This managed PoE+ switch with SFP+ ports comes with an intuitive web-based interface. Advanced managed switch features include LACP to group ports together to increase bandwidth between switches, VLANs for segmenting and isolating virtual LAN groups, QoS for traffic prioritization, port bandwidth controls, and SNMP monitoring, making this a powerful solution for SMB networks. Improve voice performance by isolating and prioritizing VoIP traffic from normal data traffic with the easy-to-use voice VLAN feature.Free up router resources by offloading routing processes to the managed switch by using the L2+ Managed IPv4/IPv6 static routing feature to efficiently route traffic at the switch level. The dynamic ARP inspection feature helps protect connected devices from man-in-the-middle attacks by discarding malicious and invalid ARP packets. Take advantage of the available multicast and IGMP/MLD snooping features to optimize IP surveillance system performance, and minimize network traffic. This TRENDnet Web Smart Managed PoE+ Switch also features 10G SFP+ ports to support long-distance fiber networking applications.Installers and integrators can save on equipment costs and reduce installation time with TRENDnet's Web Smart Managed PoE+ Switches by delivering up to 30W per port of PoE power and data over existing Ethernet cables. With PoE technology, users only need one set of cables to deliver both data and power. With this PoE+ managed switch, network PoE devices such as high-power wireless access points, PTZ and other advanced IP cameras, VoIP phone systems, IPTV decoders, access controls, and more.

Producent
Productnummer
3238103
Model
TPE-3524SF
EAN
0710931162523
Naar de website van de producent
Switch type
Managed
Aantal basis-switching RJ-45 Ethernet-poorten
48
Type basis-switching RJ-45 Ethernet-poorten
Gigabit Ethernet (10/100/1000)
Aantal moduleslots SPF+
4
Console port
RJ-45
Netwerkstandaard
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support
Ja
Full duplex
Ja
Half-duplex
Ja
Verbindingsaggregatie
Ja
Spanning tree protocol
Ja
Head-of-line (HOL) blocking
Ja
VLAN=ondersteuning
Ja
Virtuele LAN-functies
Private VLAN, Tagged VLAN, Voice VLAN
Aantal VLANs
4094
MAC-adrestabel
32000 entries
Switchingcapaciteit
176 Gbit/s
Verzending snelheid
130,95 Mpps
Jumbo Frames ondersteuning
Ja
Jumbo frames
9000
DHCP-functies
DHCP snooping
IGMP snooping
Ja
Multicast-ondersteuning
Ja
Beheerprotocollen
SNMP v1, v2c, v3
Aantal ventilatoren
3 ventilator(en)
Geluidsniveau
42,7 dB
Mean time between failures (MTBF)
70599 uur
AC-ingangsspanning
100 - 240 V
AC-ingangsfrequentie
50/60 Hz
Vermogensverbruik (max)
52 W
Stroomspanning bescherming
Overstroom, Kortsluiting
Power over Ethernet (PoE)
Ja
Vermogen per poort Power over Ethernet (PoE)
30 W
Totaal Power over Ethernet (PoE)-budget
740 W
Bedrijfstemperatuur (T-T)
0 - 50 °C
Breedte
440 mm
Diepte
310 mm
Hoogte
44 mm
Gewicht
4,72 kg
Certificering
CE FCC UL

Beheerfuncties

Switch type
Managed

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten
48
Type basis-switching RJ-45 Ethernet-poorten
Gigabit Ethernet (10/100/1000)
Aantal moduleslots SPF+
4
Console port
RJ-45

Netwerk

Netwerkstandaard
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support
Ja
Full duplex
Ja
Half-duplex
Ja
Verbindingsaggregatie
Ja
Spanning tree protocol
Ja
Head-of-line (HOL) blocking
Ja
VLAN=ondersteuning
Ja
Virtuele LAN-functies
Private VLAN, Tagged VLAN, Voice VLAN
Aantal VLANs
4094

Data-uitwisseling

MAC-adrestabel
32000 entries
Switchingcapaciteit
176 Gbit/s
Verzending snelheid
130,95 Mpps
Jumbo Frames ondersteuning
Ja
Jumbo frames
9000

Beveiliging

DHCP-functies
DHCP snooping
IGMP snooping
Ja

Multicast-functies

Multicast-ondersteuning
Ja

Protocollen

Beheerprotocollen
SNMP v1, v2c, v3

Design

Aantal ventilatoren
3 ventilator(en)

Prestatie

Geluidsniveau
42,7 dB
Mean time between failures (MTBF)
70599 uur

Energie

AC-ingangsspanning
100 - 240 V
AC-ingangsfrequentie
50/60 Hz
Vermogensverbruik (max)
52 W
Stroomspanning bescherming
Overstroom, Kortsluiting

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Ja
Vermogen per poort Power over Ethernet (PoE)
30 W
Totaal Power over Ethernet (PoE)-budget
740 W

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 50 °C

Gewicht en omvang

Breedte
440 mm
Diepte
310 mm
Hoogte
44 mm
Gewicht
4,72 kg

Certificaten

Certificering
CE FCC UL
