Productnummer: 2748802

Hager Humfree contactor 40a 4no 230v 3m

Humfree contactor 40A 4NO 230V Humfree for the control of circuitsGuarenteed silence during the entire life of the productCan be equipped with auxiliary contact and sealig capsRated operational voltage: 400 V Frequency: 50/60Hz Type of connection: With screw Operating temperature: -10 to 50 ° C Storage temperature: -40 to 80 ° C Connection cross-sect rigid cable: 4 / 25mm2 Connection cross-sect. flexible cable: 4 / 16mm2 To reduce the mutual heating when using several contactorsit is recommended to use the LZ060 spacerNumber of modules: 3According to standard: EN 61095

Lees meer
159,78 € 132,05 € excl. BTW
Goedkoopste privé verzending 6,99 €
Extern magazijn, 3 - 4 werkdagen levertijd

Contactor 40A 4 NO 230VAC noiselessProduct description: Contactor 40A with four normally open contacts, suitable for controlling and switching lighting systems and heating in residential and office environments where noiseless operation is desired. Rated voltage: 400V 50/60Hz. Operating category: AC1. Number of switches: 1,000,000. Operating temperature range: -10 to +50°C. Connection type: solid wire from 4-25mm2 / flexible wire from 4-16mm2.Width: three modules at a width of17.5mm each.

Producent
Productnummer
2748802
Model
ESC440S
EAN
3250612400409
AC-ingangsspanning
400 V
Certificaten van naleving
RoHS
Aantal
1

Energie

AC-ingangsspanning
400 V

Technische details

Certificaten van naleving
RoHS

Inhoud van de verpakking

Aantal
1

Bovenstaande specificaties en vermeldingen kunnen zonder voorafgaande kennisgeving door de fabrikant worden gewijzigd. Sommige teksten kunnen automatisch of machinaal zijn gegenereerd en daardoor misleidende teksten opleveren.
