Hager Contactor 40a 4no 230v 3m
Contactor 40A 4NO 230V Standard for the control of circuitsCan be equipped with auxiliary contact and sealig capsRated operational voltage: 400 V AC control voltage: 230V Frequency: 50/60Hz Type of connection: With screw Operating temperature: -10 to 50 ° C Storage temperature: -40 to 80 ° C Connection cross-sect rigid cable: 4 / 25mm2 Connection cross-sect. flexible cable: 4 / 16mm2 To reduce the mutual heating when using several contactorsit is recommended to use the LZ060 spacerNumber of modules: 3According to standard: EN 61095
133,35 €
110,21 € excl. BTW
Goedkoopste privé verzending 6,99 €
Extern magazijn, 3 - 4 werkdagen levertijd
Contactor 40A 4NO 230V 3M Product Description: Contactor rated at 40A with four normally open contacts and a voltage rating of 230V. Suitable for controlling and switching lighting systems and heating in residential and office environments. Rated voltage: 400V, frequency:50/60Hz. Operating category: AC1 Number of operations:1,000,000 Operating temperature range:-10 to +50°C Connection type:solid wire (4-25mm2) or flexible wire (4-16mm2). Width is three modules at a size of17.5mm each.
Naar de website van de producent
Contactstroom capaciteit
40 A
AC-ingangsfrequentie
50 Hz
Bedrijfstemperatuur (T-T)
-10 - 50 °C
Certificaten van naleving
RoHS
Kenmerken
Contactstroom capaciteit
40 A
Energie
AC-ingangsfrequentie
50 Hz
Eisen aan de omgeving
Bedrijfstemperatuur (T-T)
-10 - 50 °C
Technische details
Certificaten van naleving
RoHS
