Productnummer: 2892498
Hager Contactor 25a 4nc 230v 2m
Contactor 25A 4NC 230V Standard for the control of circuitsCan be equipped with auxiliary contact and sealig capsRated operational voltage: 400 V Frequency: 50/60Hz Type of connection: With screw Operating temperature: -10 to 50 ° C Storage temperature: -40 to 80 ° C Connection cross-sect rigid cable: 1 / 10mm2 Connection cross-sect. flexible cable: 1 / 6mm2 To reduce the mutual heating when using several contactorsit is recommended to use the LZ060 spacerNumber of modules: 2According to standard: EN 61095
66,60 €
55,04 € excl. BTW
Goedkoopste privé verzending 6,99 €
Extern magazijn, 3 - 4 werkdagen levertijd
Contactor 25A 4P 230VAC 2M Product description: Contactor 25A with four poles and a voltage rating of 230VAC. Suitable for controlling and connecting lighting systems and heating in residential and office environments. Rated voltage: 400V, frequency:50/60Hz Operating category: AC1 Number of connections:1,000,000 Operating temperature range:-10 to +50°C Connection type:solid wire (1-10mm²) or flexible wire (1-6mm²) Width:2 modules at a size of17.5mm each.
Producent
Productnummer
2892498
Model
ESC426
EAN
3250612400935
Naar de website van de producent
AC-ingangsspanning
400 V
Certificaten van naleving
RoHS
Aantal
1
Energie
AC-ingangsspanning
400 V
Technische details
Certificaten van naleving
RoHS
Inhoud van de verpakking
Aantal
1
Bovenstaande specificaties en vermeldingen kunnen zonder voorafgaande kennisgeving door de fabrikant worden gewijzigd. Sommige teksten kunnen automatisch of machinaal zijn gegenereerd en daardoor misleidende teksten opleveren.
